Other Information | Wire Types: 20 to 75 Micron Gold and Aluminum Ribbon 30 to 250 Micron
Bond Head: 90 Degree Wire Feed Electronic Touchdown Sensing for every bond Programmable Output Ultrasonic System, 0 to 5 Watt 100 KHz Programmable Bond Force 15 to 150 cN
Working Area: Y Axis, 50mm Z Axis, 50mm 2.5 Micron Resolution Standard Work Height 136mm (Mid Z Stroke) X/Y Manipulator from 5 x 5 mm to 18 x 18 mm Equivalent Manipulator Step-Down 1:2 to 1:7
Operating Modes: Semi-Automatic, Automatic, Multi-Wire Step Mode For Program Debug Loops: Standard Rectangular, Standard Triangular, Single Reverse, Double Reverse Stitch; Table Tear
Program Storage: Up to 50 Individual Wires Per Program, 250 Programs Per 3.5" Floppy Disk |
